GC-Type Polyimide Carbon-Based Film – High-Performance Precursor For Artificial Graphite Films

Anhui Guofeng New Materials Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

GC-Type Polyimide Carbon-Based Film – High-Performance Precursor For Artificial Graphite Films

  • 1
  • 2
  • 3

Brand Name : Guofeng

Model Number : PI2

Certification : ISO9001, ISO14001, ISO45001, QS production license and ISO/TS16949 UK DAKKS

Place of Origin : HEFEI, CHINA

MOQ : 1 ton

Price : 1.0-2.0 USD/KG

Payment Terms : T/T,L/C,D/P,D/A,Western Union,MoneyGram

Supply Ability : 180000 TON/YEAR

Delivery Time : 1-3 weeks

Packaging Details : Pallet

Material : polyimide

Thickness : 25μm / 50μm / 75μm (±5%)

Width : Customized

Length : Customized

Package : simple/vertical/suspend/horizontal

Tensile Strength : ≥200 MPa

Dielectric Strength : ≥100 kV/mm

Volume Resistivity : ≥1×10¹⁶ Ω·cm

Moisture Absorption : <1.0% (24hrs)

Adhesion to Copper : ≥1.0 N/mm (peel)

Contact Now


GC-Type Polyimide Carbon-Based Film – High-Performance Precursor For Artificial Graphite Films




Product Overview


Our GC-Type Polyimide Carbon-Based Film is a biaxially stretched, high-carbon-yield PI film engineered specifically for manufacturing artificial graphite films through high-temperature graphitization (up to 3000°C). With ultra-high molecular orientation and optimized imidization, it delivers superior dimensional stability and carbonization efficiency—critical for thermal management materials in electronics, aerospace, and energy storage.


Key Features


✔ Controlled Carbon Yield (≥65%) – Maximizes graphite output
✔ Biaxial Stretching (MD/TD 3:1 ratio) – Ensures uniform crystal alignment
✔ Low Ash Content (<50ppm) – Minimizes impurities for high-purity graphite
✔ High-Temp Stability (≤450°C pre-carbonization) – Prevents premature degradation
✔ Customizable Thickness (25-125μm) – Tailored for target graphite density


Applications

  • Artificial Graphite Films Heat spreaders for 5G/LED devices

  • Fuel Cell Components – Gas diffusion layers (GDLs)

  • Lithium-Ion Batteries – Anode current collectors

  • Satellite Components – High-purity thermal interfaces

  • Semiconductor Tools – Wafer processing carriers



Technical Specifications




Property

Value

Material

Polyimide

Application

Artificial Graphite Films,Lithium-Ion Batteries

Thickness Range

25μm / 50μm / 75μm / 125μm (±3%)

Width

Customizable (e.g., 500mm - 1500mm)

Surface Treatment

Corona-treated

Tensile Strength (MD)

≥150

Tensile Strength (TD)

≥260

Transparency

≥ 90%




Why Choose Our Film?

  • Optimized for Graphitization – Proprietary PI formulation reduces pinholes and cracks

  • Batch Consistency – ±1% thickness tolerance for repeatable carbonization

  • Technical Support – Graphitization protocol sharing (temperature ramping, gas flow)

  • Dual Certification – Compliant with JIS K 7128 and ASTM D882




Product pictures


GC-Type Polyimide Carbon-Based Film – High-Performance Precursor For Artificial Graphite FilmsGC-Type Polyimide Carbon-Based Film – High-Performance Precursor For Artificial Graphite Films



Handling & Storage Instructions


To ensure the longevity and performance of our BOPP film, please adhere to the following guidelines:


  • Shelf Life: 6 months from the date of manufacture.
  • Storage Conditions:Store in a cool, dry place away from direct sunlight and moisture.
  • Temperature Range: 10°C - 30°C.
  • Humidity: Keep below 60% relative humidity.
  • Handling: Avoid folding or creasing the film to prevent damage.


Order Now!

Standard Formats:


 Roll Dimensions: 500mm/1,000mm width x 100-300m length
 Core ID: 3" / 6" (industrial cores)


Special Services:
 Pre-carbonized films (pre-baked at 600°C)
 Custom imidization degrees (for controlled carbonization speed

 MOQ: 200kg (sample rolls available)

Request our Graphitization Process Guide with temperature profiles for different end uses!
